Nicasio
Ver bicicleta en otro color:
- Precios: $899.00 (USD)*
- Wheel Size: 700C
- Cuadro: CroMo/Steel
- Rango de tallas: 47, 50, 52, 54, 56, 58, 60
Size Rider height range 47cm 146cm to 152cm 50cm 152cm to 160cm 52cm 160cm to 168cm 54cm 168cm to 175cm 56cm 175cm to 183cm 58cm 183cm to 188cm 60cm 188cm to 193cm - Manufacturer’s suggested retail price may not include additional shipping or preparation charges. Please contact your local Marin dealer for a quote.
AVENTURA EN CARRETERA Y SALIDAS OFF-ROAD
VIAJES DE LARGA DISTANCIA
RESISTENCIA Y PAVIMENTO EN TODAS LAS SITUACIONES CLIMATICAS
El Nicaso es para el ciclista que busca algo diferente y moderno, pero con una construcción de acero tradicional. Las líneas clásicas y los tubos de cuadro de CrMo tienen el alma de una bicicleta clásica, con la geometría y los neumáticos 700C x 30 mm-40 mm o 650B x 47 mm para permitir que los ciclistas manejen cualquier superficie.
Salta a…
Galeria
Especificaciones
Frame
Series 1 Double Butted CrMo Beyond Road, 700C Wheels, Beyond Road Geometry, Fender and Rack Mounts, Disc Mount
Fork
CrMo, Fender and Rack Eyelets, IS Disc Mount
Rims
Marin Aluminum Double Wall, 19mm Inner, Disc Specific
Hub, Rear
Forged Aluminum Alloy, Disc, 32H
Hub, Front
Forged Aluminum Alloy, Disc, 32H
Spoke, Nipples
14g Black Stainless Steel
Tires
Vee Tire Co, Road Chief, 700Cx30, Wire Bead
Derailleur, Rear
Shimano Claris 8-Speed
Derailleur, Front
Shimano Claris
Shift Lever
Shimano Claris 2x8-Speed
Crankset
FSA Tempo Compact, 50/34T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Cassette
SunRace 8-Speed, 11-32T
Brake, Front
Tektro MDC400, Road Mechanical, 160mm Rotor
Brake, Rear
Tektro MDC400, Road Mechanical, 160mm Rotor
Brake Levers
Shimano w/ Integrated Shifters
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Stem
Marin 3D Forged Alloy
Grips
Marin Comfort Tape
Headset
FSA No.8D, Sealed Cartridge Bearings
Seatpost
Marin Alloy, 27.2mm
Saddle
Marin Beyond Road Concept
Pedals
Marin Oso OEM Nylon Platform
Specifications, pricing, and availability are subject to change without notice.
Geometria
| 47 | 50 | 52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|---|
| STACK | 534.57 | 541.26 | 555.4 | 574.52 | 590.64 | 609.72 | 619.25 |
| REACH | 349.75 | 359.8 | 360.48 | 378.42 | 384.42 | 398.59 | 404.75 |
| HEADTUBE ANGLE | 70° | 70.5° | 70.5° | 72° | 72.5° | 72.5° | 72.5° |
| HEADTUBE LENGTH | 125 | 130 | 145 | 155 | 170 | 190 | 200 |
| SEATTUBE ANGLE (ACTUAL) | 74.5° | 74° | 73.5° | 73.5° | 73° | 73° | 72.5° |
| SEATTUBE LENGTH | 440 | 470 | 490 | 510 | 530 | 550 | 570 |
| TOPTUBE (EFFECTIVE) | 498 | 515 | 525 | 545 | 565 | 585 | 600 |
| BOTTOM BRACKET HEIGHT | 269 | 269 | 269 | 269 | 269 | 269 | 269 |
| BOTTOM BRACKET DROP | 72 | 72 | 72 | 72 | 72 | 72 | 72 |
| CHAINSTAY | 420 | 420 | 420 | 420 | 420 | 420 | 420 |
| Wheelbase | 992.55 | 1000.22 | 993.92 | 999.2 | 1008.92 | 1029.1 | 1038.26 |
| STANDOVER HEIGHT | 697.12 | 721.09 | 741.53 | 758.79 | 777.05 | 796.2 | 812.46 |
| FORK OFFSET | 57 | 57 | 57 | 45 | 45 | 45 | 45 |
| SEATPOST DIAMETER | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
| HANDLEBAR WIDTH | 400 | 400 | 400 | 420 | 420 | 440 | 440 |
| STEM LENGTH | 75 | 75 | 75 | 90 | 90 | 90 | 90 |
| CRANK LENGTH | 170 | 170 | 170 | 175 | 175 | 175 | 175 |
All lengths in millimeters
Tecnología
MAS ALLÁ DE LA GEOMETRÍA DE CARRERAS
Beyond Road Geometry ofrece una combinación de manejo en carretera de resistencia con estabilidad mejorada para uso fuera del pavimento.
CONSTRUCCIÓN CUADROS DE ACERO
La Nicasio utiliza un cuadro 4130 CrMo empalmado Serie 2 o Serie 1 con frenos de disco, soportes completos para guardabarros y portabultos, y dos o tres salientes de botella.
Aprende mas
FRENOS DE DISCO
Los frenos de disco proporcionan un frenado suave y controlado en todas las condiciones con un mantenimiento mínimo.
ESPACIO PARA CUBIERTAS
The Nicasio frame and fork has clearance for up to 700C x 35mm or 650B x 47mm tires.
NEW STEP-THRU VARIANT
The new Nicasio ST brings a step-thru version of the popular model. Great for those who are looking for easy mounting and dismounting, even with baskets and baby seats.
Reseñas
One of The Independent's 'Six Best Gravel Bikes Under £1000.'
