Sausalito 2 (EU/global)
See this bike in a different color:
- Price: $2,999.00*
- Frame: Aluminium
- Size Range: S, M, L, XL
Size Rider height range S 5'2" to 5'6" M 5'6" to 5'10" L 5'10" to 6'2" XL 6'2" to 6'4" - Manufacturer’s suggested retail price may not include additional shipping or preparation charges. Please contact your local Marin dealer for a quote.
Highlights
- System
- Bosch Performance Sport
- Max torque
- 70Nm
- Max assisted speed
- 25 km/h
- Battery capacity
- 600Wh
- Range
- TBD*
- Rider app
- Bosch eBike Flow
Highlights Disclaimers
* Based on rider weight, terrain, climate and level of assistance used.
Jump to…
Specifications
Frame
Series 3 Butted and Formed 6061 Aluminum, 650B Wheel, One-Piece Hydroformed Downtube Motor and Battery, Integrated Wiring, Internal Housing, Kickstand, Rack and Fender Mounts
Fork
SR Suntour NVX32, 80mm Travel, Thru-Axle
Rim
Marin Aluminum Double Wall, Disc Specific
Hub Rear
Forged Alloy, Disc Specific, 32H
Hub Front
Forged Alloy, Disc Specific, 32H
Spokes
14g Black Stainless Steel
Tires
Vee Tire Co., Shift, 27.5x2.35, Puncture Resistant
Derailleur Rear
Shimano CUES 10-Speed
Derailleur Front
-
Shift Lever
Shimano CUES 10-Speed
Crankset
Forged Aluminum w/ 38T Steel Chairing
Motor
Bosch Performance , 250W, 75Nm, Class 1 (25Km/h)
Battery
Bosch PowerTube 600, 600Wh
Chain
KMC E11S
Cassette
Shimano CUES 10-Speed 11-48T
Brakes Front
Shimano MT201 Hydraulic, 180mm Rotor
Brakes Rear
Shimano MT201 Hydraulic, 180mm Rotor
Brake Levers
Shimano MT201 Hydraulic
Stem
Marin Alloy
Grips
Marin Adventure
Headset
FSA No. 57E
Seatpost
Marin Alloy, 30.9mm
Saddle
Marin City Plush
Pedals
Nylon Platform
Extras
Bosch Purion 200 LCD Display, Lezyne Power STVZO E500+ Lights, Rear Mount Alloy Kickstand
Range, Charging Time
25-93 miles/40-150km, (Based on Rider Weight, Terrain, Climate and Level of Assist Used), 4 Hours (estimated, under ideal conditions)
Specifications, pricing, and availability are subject to change without notice.
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Stack | ||||
| Reach | ||||
| Head Tube Angle | 69.5° | 69.5° | 69.5° | 69.5° |
| Head Tube Length | ||||
| Seat Tube Angle | 74° | 74° | 74° | 74° |
| Seat Tube Length | ||||
| Top Tube Effective | ||||
| BB Height | ||||
| BB Drop | ||||
| Chain Stay | ||||
| Wheel Base | ||||
| Stand Over Height | ||||
| Fork Offset | 44 | 44 | 44 | 44 |
| Seatpost Diameter | 27.2 | 27.2 | 27.2 | 27.2 |
| Handlebar Width | 720 | 740 | 740 | 740 |
| Stem Length | 45 | 45 | 45 | 45 |
| Crank Length | 170 | 170 | 175 | 175 |
All lengths in millimeters
Technology
SERIES 3 ALUMINUM FRAME
The standard and step-through versions of Sausalito feature a Series 3 aluminum frame with butted tubes and robust forgings, specifically designed to house the drive unit and removable battery, as well as mount a variety of commute accessories directly to the frame.
SHIMANO STEPS
The Sausalito 2 features the Shimano STEPS EP6 motor system with 250 Watts and 85Nm of torque for a good get-up-and-go feeling, with long range and enough power to get you over the steepest of climbs. The Sausalito 1 features a Shimano STEPS E5000 system with 250 Watts and 40Nm of torque.
FORKS
The BMX inspired steel fork on Sausalito 1 and 63mm travel suspension fork on Sausalito 2 smooth out and stabilize the front of the bike when roads get rough.
REMOVABLE BATTERY
The battery is secured direct to the frame with a key lock, and is easy to remove to carry with you for charging. Sausalito 1s include a 418Wh battery, while the Sausalito 2 models step up to a 504Wh battery.
